Description
Snap Disc Thermostat Switch. Turns On Axial fan at 100°F and Off at 90°F.
PO-6
Power outlet with mounting bracket, 16/3 grounded wire, 5 outlets, 15 Amp breaker.
WH-AF-100
Axial Fan, 110V, 50/60 Hz., 100 CFM free air capacity, mounts in the apex of weather house roof. Removes excess heat generated by pumps or sun.
WH-EL
Extended Legs, elevates weather house to 67” above the ground (to peak).
WH-GFI-2 & WH-GFI-4
2 or 4 Outlet GFCI Conduit Box hard mounted in Weather House – 115 VAC – 15 AMP.
WH-SL
Standard Legs, elevates weather house to 48″ above the ground (to peak).
WH-GN
Standard gooseneck assembly for weather house. Allows operator to sample at DOE designated breathing levels by mounting the filter holder assembly externally 59” above the ground. 5/8” Stainless Steel Tube with 3/8” brass Female Quick Disconnect on inlet and 3/8” brass Male Quick Disconnect on outlet. Gooseneck assembly includes all mounting hardware & support bracket. Custom tubing lengths available. Add a “-WHITE” or “-BLUE” to part number for color selection.
WH-6X10LS
Replacement 6″ x 10″ internal screen & louver set (3 set louvered door).
WH-LS
Lamp outlet with pull chain. Used for lighting or a heat lamp.
GN-R&WS
Rain & Wind Shield for filter holders externally mounted on gooseneck. Includes 3/8” male & female quick disconnect for easy installation. Rain & Wind Shield is shown attached to upper half of HI-Q’s standard “Gooseneck” assembly, P/N: WH-GN.
